Thermal Insulation Panel for Poultry House Construction

Product Introduction

With the rapid growth of the poultry industry, traditional brick-and-mortar chicken houses face serious drawbacks, including exorbitant construction costs, poor insulation, difficult disinfection, and environmental restriction on clay bricks. Our New Magnesium FRP Thermal Insulation Panel System is engineered to completely replace traditional masonry while overcoming the historical flaws of early magnesium materials (such as cracking, halogenation, and salt blooming) through scientific polymer modification.

The insulation panel consists of an organic fiber cloth reinforced inorganic composite surface (magnesium cement, FRP, cement matrix) combined with a high-performance insulating core (flame-retardant EPS foam board or export-grade roll-packed glass wool). Roll glass wool options offer easier shipping container loading and higher thermal insulation for international projects.

Designed for open, windowed, or fully closed climate-controlled poultry housing, the panels are factory-prefabricated and assembled on-site with column vertical supports. A 10cm thick panel delivers insulation performance equivalent to a 50cm solid brick wall, reducing winter heating coal usage by half and blocking summer solar radiation. Its mirror-smooth, acid-and-alkali-resistant surface enables rapid high-pressure washing and thorough chemical disinfection, creating a safe, hygienic environment that minimizes disease risks and lowers overall breeding costs.

Specifications Reference

Technical Indicators

1. Thermal Efficiency Ratio: 10cm magnesium sandwich panel achieves thermal resistance equal to a 50cm brick wall; cuts winter heating coal by 50%.
2. Fireproof Grade: Inorganic magnesium binder surface withstands temperatures exceeding 1000°C without combustion.
3. Cost Savings: Construction cost is reduced by 100 to 140 RMB/m² compared to clay brick buildings.
4. Acoustic Insulation: Porous insulation core absorbs environmental noise, protecting poultry from stress.
5. Freeze-Thaw Resistance: High flexural strength and elasticity prevent freeze-cracking in harsh cold northern climates.

Manufacturing Standards

1. Scientific Polymer Modification: Formulated with advanced polymer binders to permanently eliminate salt blooming, halogenation, and warping cracking.
2. Fire-Retardant Core Material: EPS foam cores must incorporate flame-retardant additives; export variants utilize high-density roll-packed glass wool for optimal transport and thermal density.
3. Mirror-Smooth Surface Finish: Composite mesh and inorganic binder are pressed under high pressure to create a mirror-smooth, pore-free surface that inhibits bacterial harborage.
4. Prefabricated Modular Columns: Engineered vertical support columns allow rapid interlocking bolt connection during on-site erection.

Product Advantages

1. Ultra-Low Construction Cost: Costs under 70 RMB/m² compared to 250-300 RMB/m² for red brick, complying with clay brick restriction policies.
2. Exceptional Thermal Insulation: 10cm panel matches a 50cm brick wall, cutting winter coal usage by 50% and blocking summer heat radiation.
3. Fast Construction Speed: Prefabricated modular panels allow 10 workers to erect a 756m² barn (72m x 10.5m for 5000 broilers) in just 6 to 8 days.
4. Superior Disease Prevention & Washability: Mirror-smooth, water and acid-resistant surface leaves no place for bacteria to hide, making high-pressure washing and disinfection effortless.
5. Fireproof & Freeze-Resistant: Withstands 1000°C fire temperatures; high elasticity prevents freezing cracks in cold northern areas.
6. Acoustic Protection & High Space Utilization: Porous core material absorbs external noise; column support layout improves air circulation and housing ventilation.
7. Long Service Lifespan: Chemically modified magnesium FRP composite provides 20 to 30+ years of durable operation.

Daily Maintenance

1. Wash wall surfaces thoroughly with high-pressure water and farm disinfectants after each flock turnover.
2. Inspect the sealant strips between modular panels annually and re-seal if physical damage occurs.
3. Check side windows, skylights, and column anchor bolts periodically after extreme wind storms.

OEM / ODM Customization Services

1. Core Material Customization: Choice of flame-retardant EPS foam boards or container-friendly roll glass wool.
2. Panel Thickness Customization: Available in 50mm, 75mm, or 100mm wall thickness options.
3. Turnkey Poultry House Dimensions: Tailored layouts for open, windowed, or closed barns (e.g. 72m x 10.5m with 12 skylights and 48 side windows).
4. Structural Frame Customization: Supporting steel columns, roof trusses, and window frames produced to customer building drawings.

FAQ

Q1: How does this modified magnesium panel solve traditional salt blooming and cracking issues?
A1: By introducing high-molecular polymer binders and precision chemical modifiers, the free chloride ions are chemically bound, preventing salt blooming, halogenation, and embrittlement.

Q2: Why is glass wool roll preferred over foam board for international export orders?
A2: Glass wool rolls can be compressed and vacuum-packed, significantly saving ocean container volume while delivering higher thermal insulation and superior fire resistance.

Q3: Can 10 workers really assemble a 756 m² chicken house in 6–8 days?
A3: Yes. Because all panels, columns, and roof trusses are 100% prefabricated in our factory, on-site labor only involves modular bolt connection and seam sealing, drastically shortening construction cycles.
